Description

Hall effect crankshaft or camshaft position sensor. It is a new version, distinguished by its red anodized aluminum casing. Threads are M12 and mounting nuts are included. It runs from 5 to 24 volts and offers a nice square wave so there are no variable voltage issues. It has a 1 meter long ponytail with 3 strands. This is what the wires do:

Brown: supply voltage; connect to +5v for 5 volt operation or 12 volt switched power.

Black: exit sign. Connects to VR1+. Note that this requires a pull up resistor. This connects to both the supply voltage and the output signal cable. Use a 1K resistor when feeding it 5 volts or a 2.4K resistor when feeding it 12 volts.

Blue – Earth.

specs

Operating voltage: 5 to 24 volts

Maximum surge and reverse voltage: +30 to -24 volts

Required maximum supply current: 6 mA

Maximum output current sink: 20mA

Output Type: Open Collector

Maximum frequency: 15kHz

Temperature range: -40 to +125 degrees C

Nominal Air Gap: 1.5mm

Thread pitch: M12 x 1mm

Total length: 25.4 mm, not including cables

Package Material: Aluminum

Sensor orientation: non-directional

The recommended tooth size is a rectangle at least 2.5mm x 6.35mm, with a tooth height of 5.0mm.
